BSF 27-4

Flexibility with the BSF 27-4 - Ideal for any application

The BSF 27-4  is the perfect solution for pumping in inner-city areas, concreting bridges, hose
applications, and much more thanks to the TRC pedestal.

The newly designed BSF 27-4 boom improves flexibility with a 100° a-angle and provides the
highest boom on 2-axle trucks. Boom vibrations and wobbling are reduced by laying the delivery lines in neutral and straight arms. Service-friendly access, all pipe on one side of the boom, standardized pipe bends, and screwed pipe supports allow for quick delivery line replacement.

Our  TRC design (Trapezium Compact) is a further development of our TRD system – now even more compact with double telescopic support legs with a 10% smaller support area. The TRC not only saves a lot of space – 500 to 600 mm compared to the TRD – but also offers the option of infinitely variable support. The stability of the unit is also improved, supported by a reduced weight that allows for a higher payload.

Informações gerais

  • Braços
    4
  • Alcance Vertical
    86'7"
  • Alcance Horizontal
    72'6"
  • Altura de Desdobramento
    22'0"
  • Rotação
    °
  • Extremidade da Mangueira - Comprimento
    10'0"
  • Mangueira Terminal - Diâmetro
    5"
  • Espalhamento do suporte E-D - frente hidraulicamente estendida para fora e para baixo
    18'11"
  • Outrigger spread: L-R-rear hydraulically extend down
    7'11"
  • Comprimento x Largura x Altura
    31'5"x8'2"x12'2"
  • Distância entre Eixos
    189"
  • Peso do Eixo Dianteiro
    13324
  • Peso do Eixo Traseiro
    23000 lbs
  • Peso total aproximado
    36324

Características principais

  • Lowest possible support area for inner-city pumping
  • Flexible double telescopic support legs provide stability in any position
  • Rear support cylinders for shorter paths in the working area
  • Generous space for storage containers and hoses

Configuração

  • Diâmetro do Cilindro de Material-Comprimento do Curso
    9"/55"
  • Saída (lado do pistão)
    158 yd³/hr
  • Pressão (lado do pistão)
    1189 psi
  • Cursos (lado do pistão)
    35
